FLOAT EQUIPMENT WITH FLAPPER VALVES ARE KEY COMPONENTS FOR RUNNING CASING AND PERFORMING CEMENTING OPERATIONS.
During cementing operations, float equipment is essential for preventing back-flow while also serving as a landing point for wiping and displacement plugs. When surge pressures on the formation are a concern, Top-Co brand float equipment can be configured to auto-fill to prevent formation damage.
MAKING IT BETTER
Flapper style auto-fill float equipment allows for automatic filling of fluid within the casing.
Automatic filling also reduces casing running time by eliminating the need to fill from surface as well as lowering surge pressures on formations.
PRODUCTS
TYPE 295/296 - ALUMINUM FLAPPER FLOAT EQUIPMENT
Type 295/296 - Aluminum Flapper valve is specifically designed for use with high concentrations of lost circulation material (LCM). The open bore of the hinged flapper valve permits solids to pass through without clogging the valve. The valve is made from aluminum and is 100% PDC drillable.
PRODUCT INFORMATION
DOWNLOAD
TYPE 285 /286 - CAST IRON VALVE
Type 285/286 cast iron flapper valve has been specifically engineered for extreme service applications, most notably for high temperatures or with high concentrations of lost circulation materials (LCM).
PRODUCT INFORMATION
DOWNLOAD
TYPE 537/538 - FLOAT COLLAR AND SHOE, BIG BORETM AUTO-FILL
Top-Co Type 537 Big BoreTM Auto-Fill Float Collar and Type 538 Big BoreTM Auto-Fill Float Shoe allow for automatic fill from bottom while casing is being run in the hole. The valve is run in hole fully open which allows the casing to completely fill.
PRODUCT INFORMATION
DOWNLOAD
TYPE 535/536 - FLOAT COLLAR AND SHOE, DIFFERENTIAL-FILL
Type 535 Differential Fill Float Collar and Type 536 Differential Fill Float Shoe allow for automatic filling and leveling of the fluid within the casing while it is being run in the hole. The differential fill float equipment consists of a sleeve that operates under differential pressure allowing the inflow of fluid to fill the casing 80-90% before shifting closed from the fluid pressure acting above the valve.
PRODUCT INFORMATION
DOWNLOAD
MANUAL CONVERSION
DOWNLOAD
TYPE 207 - INSERT FLOAT VALVE
Type 207 - Insert Float Valve is a hinged flapper style valve that is installed in API 8RD and BTC casing couplings for shallow/low bump and back pressure wells.
