GUIDE THE CASING TO TOTAL DEPTH WHILE PROVIDING MAXIMUM CIRCULATION.
A guide shoe is installed on the bottom joint of casing and is usually combined with a float collar in the casing string for conventional cementing operations. The guide shoe thru-bore allows conversion balls, tubes and debris to exit the casing without obstruction.
FEATURES
Rounded cement bull nose allows for smooth running and provides the ability to guide past ledges
Composite eccentric nose available
Load bearing capability for setting on bottom
PDC drillable
Available on special order for any casing grade or premium thread
Available in sizes 2.375 in to 30 in
Texas pattern/saw tooth
Side ports
Down-jets
Up-jets
